V3 Large Touch Display

GM65V25AZD  GM75V25AZD GM86V25AZD
Size
  • 65
  • 75
  • 86
  • AG Temper Glass 4mm /7H
  • Android 9.0&Infrared Touch 40pt
  • Support Stylus&Switch between multiple contexts
  • Can do meeting and class
Model No.GM65V25AZDGM75V25AZDGM86V25AZD
LED Panel
Screensize(Diag)657586
Resolution3840 x 2160
Aspect Ratio16:9
Brightness450cd/ ㎡
Contrast Ratio5000:1
Viewing Angle178°/178°
Response Time6 ms
Backlight UnitDirect LED
Backlight Life50,000 hours
Touch
Touch TechnologyInfrared Touch 40pt
Touch Resolution32767 x 32767
OS  CompatiblityWin 11/10/8/7:40pt, Win XP:1pt, Mac:1pt, Android:20pt, Linux:1pt, Chrom:1pt
Tempered GlassAnti-tempered glass  4 mm / 7H
Connectivity Input
Video(Analog)VGAx1, AVx1, YPbPrx1
Video(Digital)HDMI 2.0x3,DP 1.2x1
AudioAudio in(3.5mm)x1,Mic(3.5mm)x1
Media(Android)USB3.0 A-type x4, USB-C x1, Micro SD Carel slot x1, USB2.0 A-type x1
MediaUSB 3.0 A-type x3
LANRJ45x1
Screen ControlRS232C (In/Out)x1
OPS SlotSupport Max 4K/60 fps
Media systemSupport PAL, NTSC, SECAM system
Connectivity Output
Video(Digital)HDMI 2.0 x1
AudioSPDIF (Optical) x1, Earphone x1
TouchUSB 2.0 B-type x5
LANRJ45x1
Audio
Speakers16Wx2
Power
Input VoltageAC100-240 V 50/60 Hz
Typical≦ 220W≦ 330W≦ 410W
Standby≦ 0.5W
Environmental
Operation Temperature0-40 ℃
Operation Humidity20-80% RH
Size and Weight
Dimensions1471 x 897.5 x 100.5 mm1692 x 1022 x 100.5 mm1943 x 1166 x 100.5 mm
VESA Mounting600 x 400 mm800 x 600 mm
Net Weight45 kgs62 kgs76 kgs
Android
System VersionAndroid 9.0
CPUA73x4
GPUMali-G71-MP3
RAM4 GB
ROM32 GB


  • Power Cord(US)3m x 1
  • HDMI Cable 3m x 1
  • Touch USB Cable 3m x 1
  • Remote Control x 1
  • Stylus x 2
  • Wi-Fi Dongle x 1
  • Quick Start Guide x 1
  • Screws(M8)x4
  • Wall Mount Kit x 1
The following are product notes:
1. Before using the product, please carefully read the safety history book in the accessory box and keep it for future reference.
2. Please use the power cord and accessories provided with the product.
3. Do not bend, twist or pull the power cord forcibly.
4. For the installation method, please follow the "Wall Mounting Installation Instructions" in the wall mounting bracket for installation.
5. If the product is not used for a long time, please turn off the power and remove the plug.
6. In order to avoid fogging of the product, please put the product in the same space (without power on) for 1 to 2 hours, let the temperature/humidity of the product be close to the temperature/humidity of the space before turning on the product.

Product Remark

*86 inches sold out
