E1 55 Touch Display

GM55Q32LZS
Size
  • 55
  • High precision low Z axis touch design
  • Built-in Android OS 8.0 platform,32-point touch
  • Full-featured Type-C port
  • Support double-touch pen operation and various backgrounds switching
  • Switch between conference and teaching
  • High precision low Z axis touch design
  • Built-in Android OS 8.0 platform,32-point touch
  • Support double-touch pen operation and various backgrounds switching
  • Switch between conference and teaching
  • High precision low Z axis touch design
  • Built-in Android OS 8.0 platform,32-point touch
  • Support double-touch pen operation and various backgrounds switching
  • Switch between conference and teaching

  • Touch USB Cable 3m x1
  • HDMI Cable 3m x1
  • Power Cord 3m x1
  • Quick Start Guide x1
  • Stylus x2
  • Wi-Fi Module x1
  • Remote Control x1
  • M8 Screw x4
  • Wall Mount Kit x1
Model No.GM55Q32LZS
LED Panel
Screen Size(Diag.)55"
Resolution3840 x 2160
Aspect Ratio16:9
Brightness450cd/㎡
Contrast Ratio4000:1
Viewing Angle178°/178°
Responses Time6 ms
Backlight UnitDirect LED
Backlight Life50,000 hours
Touch
Touch TechnologyInfrared 32pt Touch
Touch Resolution32767 x 32767
Touch Accuracy≧∅3mm
OS compativilityWin 10/8/:32pt, Win XP:1pt, Mac:1pt,
Android:16pt, Linux:1pt, Chrome:1pt
Tempered GlassAnti-glare 4mm
Audio
Speakers16W x2
Power
Input VolitageAC100-240V 50/60Hz
Typical≦ 220W
Standby≦ 0.5W
Environmental
Operation Temperature0-40℃/20-80% RH
Connectivity Input
Video (Analogue)VGA x1, AV x1, YPbPr x1
Video (Digital)HDMI 2.0 x3, DP 1.2 x1
AudioAudio in (3.5mm) x1, Mic (3.5mm) x1
Media (Android)USB3.0 A-Type x1, SD Card Slot x1
MediaUSB 3.0 A-Type x3
LANRJ 45 x1
Screen ControlRS232C (In/Out) x1
OPS SlotSupport Max. 4K/60fps
Connectivity Output
Video (Analogue)AV x1
Video (Digital)HDMI 2.0 x1
AudioSPDIF Coaxial x1, Audio out(3.5mm) x1
TouchUSB 2.0 B-Type x5
LANRJ 45 x1
Physical Spec.
Dimension (WxHxD)1286 x 766 x 90mm
VESA mounting400 x 400mm, 100 x 100 (Mini PC)
Net Weight34.3kgs
Android
System VersionAndroid 8.0
Kernel4.9
CPUDual Core A73 + Dual Core A53 1.5GHz
GPUQuad Core Mali G51
RAM4GB
ROM32GB
The following are product notes:
1. Before using the product, please carefully read the safety history book in the accessory box and keep it for future reference.
2. Please use the power cord and accessories provided with the product.
3. Do not bend, twist or pull the power cord forcibly.
4. For the installation method, please follow the "Wall Mounting Installation Instructions" in the wall mounting bracket for installation.
5. If the product is not used for a long time, please turn off the power and remove the plug.
6. In order to avoid fogging of the product, please put the product in the same space (without power on) for 1 to 2 hours, let the temperature/humidity of the product be close to the temperature/humidity of the space before turning on the product.
